1. Electrical connection
Voltage 230 V 1~50 Hz
Connected load 1,8 kW
Protection class IP X5
Protective class I
Mains fuse (slow-blow) 10 A
2. Water connection
Max. feed pressure 0,8 MPa
Max. feed temperature 40 C
Min. feed volume 9 I/min
Max. Suction height 0,5 m
3. Performance data
Working pressure 11 MPa
Max. permissible pressure 13 MPa
Water flow rate 6,3 I/min
Max. feed volume 7,0 I/min
Detergent flow rate 0,3 I/min
Recoil force of trigger gun 16 N
4. Dimensions and weights
Length 300 mm
Width 394 mm
Height 876 mm
Weight, ready to operate with accessories 13,0 kg
5 Values determined as per EN 60335-2-79
Hand-arm vibration value Uncertainty K <2,5 m/s2 0,3 m/s2
Sound pressure level LpA Uncertainty KpA 73 dB(A) 2 dB(A)
Sound power level LWA + Uncertainty KWA 89 dB(A)
Specification
- Length (mm.) - 300
- Width (mm.) - 394
- Height (mm.) - 876
- Weight netto (kg.) - 11.8
- Weight brutto (kg.) - 16.1
