-Supply voltage Ph/V/Hz 1 / 230 / 50
-Flow rate (l/h) 350 - 700
-Pressure (bar/MPa) 30 - 120 / 3 - 12
-Max. temperature (C) 80 - 155
-Connection load (kW) 3.4
-Heating oil consumption, full load (kg/h) 4.6
-Fuel tank (l) 25
-Weight (kg) 146
-Dimensions (L W H) (mm) 1330 x 750 x 1060
-Detergent tank (l) 20 - 10
Equipment:
-Spray gun, Easy Press trigger gun
-Trigger gun with soft grip insert
-Pressure hose, 10 m
-Spray lance, 1050 mm
-Power nozzle
-Anti-twist system
-Tanks for cleaning agent, calcification protection and fuel can be conveniently filled from the outside
-Control panel with display light
-Three-piston axial pump, With ceramic pistons
-Pressure cut-off
-Service electronics
-Service electronics with LED display
-Two cleaning agent tanks
-Dry-running protection
Specification
- Length (mm.) - 1330
- Width (mm.) - 750
- Height (mm.) - 1060
- Weight netto (kg.) - 158
- Weight brutto (kg.) - 179
