Current type Ph/V/Hz 3/400/50
Flow rate (l/h) 450-900
Pressure (bar/MPa) 30-180/3-18
Max. temperature (C) 80-155
Connected load (kW) 6.4
Heating oil consumption, full load (kg/h) 5.8
Fuel tank (l) 25
Fuel tank (cc) -
Weight (kg) 156
Dimensions (L x W x H) (mm) 1330x750x1060
Detergent tank (l) 20-10
Equipment:
-Spray gun, Easy-press trigger gun
-Spray gun with soft grip
-High-pressure hose, 10 m
-Spray lance, 1050 mm
-Power nozzle
-Servo control
-Anti-twist system
-Cleaning agent, scale inhibitor and fuel tanks can be filled from outside
-Control bar with display light
-Three-piston axial pump, with ceramic piston
-Pressure cut-off
-Pole reversing plug (3-phase)
-Electronic service control
-Electronic service control with LED display
-Two detergent tanks
-Dry running protection
Specification
- Length (mm.) - 1330
- Width (mm.) - 750
- Height (mm.) - 1060
- Weight netto (kg.) - 158
- Weight brutto (kg.) - 184
